Delta HMI TP Series TP70P-RM2 / TP70PRM2

A human machine interface (HMI) is a platform which permits interaction between users and automation equipment. Delta’s HMI products provide various communication ports for fast communication and convenient control of a diverse range of machines, systems and facilities. The color touchscreen enables intuitive parameter entry and a variety of ways to display variable data, including trend graphs and alarm elements. The high resolution LCD display visualizes operating, monitoring and efficient control in real time. In addition, the user-friendly editing software guides users in quickly creating easy-to-navigate visual icons and easily designing intuitive monitoring screens for applications, while making adjustments, scheduling, and programming operational sequences that enhance flexibility and save development time. This achieves rapid system development that simplifies wiring and installation, saves operating expenses, and makes systems more efficient, eliminating time-consuming adjustment and additional maintenance costs.

DOP-B Series

• The DOP Series Human Machine Interface (HMI) provides various touch screens with multiple dimensions and colors. It also offers fast and convenient control functions for industrial automation machines. In addition, Delta Windows-based and user-friendly DOPSoft Screen Editor and Programming Software configures the whole DOP Series. With DOPSoft, users can quickly edit images and graphs and easily set suitable communication protocol. More applications can be created, edited, downloaded and uploaded.

• The DOP-W Series is a large Human Machine Interface (HMI) that comes with a high resolution and high brightness touch screen in 10.4”, 12” and 15” sizes. With the latest Cortex-A8 processor for up to 1GHz pulse wave, the DOP-W Series delivers high performance with rapid response. Its rugged and CE-certified aluminum enclosure protects from vibration and changing ambient temperatures, and features an IP65 waterproof front panel for harsh environments. Built-in stereo speakers increase utility and flexibility. The DOP-W Series complies with CE and UL safety approvals and provides an efficient and competitive solution to meet customer needs for a wide range of high-end industrial automation applications.

• The HMC Series is a new and advanced human machine interface which has additional built-in PLC functions for sequence control. To make high precision control and high level performance possible, the HMC Series is equipped with two high-speed CPUs which ensure the execution efficiency and the performance of the system when running large and complicated PLC programs. Using Delta's DMCNET high speed and real time communication bus, the HMC Series is capable of connecting to the ASDA Series servo drives to provide high-performance synchronous motion control to meet the demanding requirements of high speed movement and high precision positioning.

• The TP70P Series adopts a 65535 colors LCD touchscreen, supports Delta’s controllers, and can be connected to all series of Delta’s AC servo drives, AC motor drives, and temperature controllers. With four models providing different I/O configurations and supporting various output types, the TP70P Series’ high flexibility saves wiring cost and offers the best HMI and I/O control solution.
