All items we supply are 100%
Siemens factory sealed with
1 year warranty !
Product Details:
Payment & Shipping Terms:
|
| 6SL3210-1KE22-6AB1 | SINAMICS G120C RATED POWER 11,0KW | $753.00PCS | IN STOCK |
| 6SL3210-1KE22-6AP1 | SINAMICS G120C RATED POWER 11,0KW | $780.00PCS | IN STOCK |
| 6SL3210-1KE22-6AF1 | SINAMICS G120C RATED POWER 11,0KW | $780.00PCS | IN STOCK |
| 6SL3210-1KE22-6AC1 | SINAMICS G120C RATED POWER 11,0KW | $791.00PCS | IN STOCK |
| 6SL3255-0AA00-4JA0 | SINAMICS G120 INTELLIGENT OPERATOR PANEL(IOP) | $167.00PCS | IN STOCK |
| 6SL3255-0AA00-4HA0 | SINAMICS G120/G120D AND SIMATIC ET200S FC/ET200 | $311.00PCS | IN STOCK |
| 6SL3255-0AA00-4CA1 | SINAMICS G120 BASIC OPERATOR PANEL (BOP-2) | $37.00PCS | IN STOCK |
| 6SL3256-0AP00-0JA0 | SINAMICS G120 DOOR MOUNTING KIT IP54/UL | $33.00PCS | IN STOCK |
| 6SL3254-0AM00-0AA0 | MMC PARAMETER STORAGE FOR ET 200S | $50.00PCS | IN STOCK |
| 6SL3054-4AG00-2AA0 | SINAMICS SD-CARD 512 MB EMPTY | $39.00PCS | IN STOCK |
| 6SL3255-0AA00-2CA0 | SINAMICS G120 PC-CONVERTER-CONNECTION-KIT-2 | $31.00PCS | IN STOCK |
| 6SL3243-0BB30-1HA3 | SINAMICS G120 CONTROL UNIT CU230P-2 | $150.00PCS | IN STOCK |
| 6SL3243-0BB30-1PA3 | SINAMICS G120 CONTROL UNIT CU230P-2 | $167.00PCS | IN STOCK |
| 6SL3243-0BB30-1FA0 | SINAMICS G120 CONTROL UNIT CU230P-2 | $167.00PCS | IN STOCK |
| 6SL3243-0BB30-1CA3 | SINAMICS G120 CONTROL UNIT CU230P-2 | $178.00PCS | IN STOCK |
| 6SL3244-0BB00-1BA1 | SINAMICS G120 CONTROL UNIT CU240B-2 |
$92.00PCS
|
IN STOCK |
| 6SL3244-0BB00-1PA1 | SINAMICS G120 CONTROL UNIT CU240B-2 | $120.00PCS | IN STOCK |
| 6SL3244-0BB12-1BA1 | SINAMICS G120 CONTROL UNIT CU240E-2 | $133.00PCS | IN STOCK |
| 6SL3244-0BB12-1PA1 | SINAMICS G120 CONTROL UNIT CU240E-2 | $161.00PCS | IN STOCK |
| 6SL3244-0BB12-1FA0 | SINAMICS G120 CONTROL UNIT CU240E-2 | $161.00PCS | IN STOCK |
|
Terminal No.
|
Signal
|
Features
|
|---|---|---|
|
Digital inputs (DI) – Standard
|
||
|
69
|
DI COM
|
Reference potential for digital inputs
|
|
5 ... 8.
16.17 |
DI0 … DI5
|
Freely programmable
isolated, inputs in compliance with IEC 61131-2 |
|
Digital outputs (DO)
|
||
|
18
|
DO0, NC
|
Relay output 1
NC contact (5 A, 30 V DC or 2 A, 250 V AC) 1) |
|
19
|
DO0, NO
|
Relay output 1
NO contact (5 A, 30 V DC or 2 A, 250 V AC) |
|
20
|
DO0, COM
|
Relay output 1
Common contact (5 A, 30 V DC or 2 A, 250 V AC) 1) |
|
21
|
DO1, NO
|
Relay output 2
NO contact (0.5 A, 30 V DC) |
|
22
|
DO1, COM
|
Relay output 2
Common contact (0.5 A, 30 V DC) |
|
23
|
DO2, NC
|
Relay output 3
NC contact (5 A, 30 V DC or 2 A, 250 V AC) 1) |
|
24
|
DO2, NO
|
Relay output 3
NO contact (5 A, 30 V DC or 2 A, 250 V AC) |
|
25
|
DO2, COM
|
Relay output 3
Common contact (5 A, 30 V DC or 2 A, 250 V AC) 1) |
|
Analog inputs (AI)
|
||
|
3
|
AI0+
|
Differential input, switchable between current and voltage
Value range: 0 ... 10 V, -10 ... +10 V, 0/2 ... 10 V, 0/4 ... 20 mA |
|
4
|
AI0-
|
|
|
10
|
AI1+
|
Differential input, switchable between current and voltage
Value range: 0 ... 10 V, -10 ... +10 V, 0/2 ... 10 V, 0/4 ... 20 mA |
|
11
|
AI1-
|
|
|
50
|
AI2+
|
Non-isolated input, switchable between current and temperature sensors, type Pt1000/LG-Ni1000
Value range: 0/4 ... 20 mA, Pt1000: -50 ... +250 °C LG-Ni1000: -50 ... +150 °C |
|
51
|
GND
|
Reference potential of the AI2/internal electronics ground
|
|
52
|
AI3+
|
Non-isolated input for temperature sensors, type Pt1000/LG-Ni1000
Value range: Pt1000: -50 ... +250 °C LG-Ni1000: -50 ... +150 °C |
|
53
|
GND
|
Reference potential of the AI3/internal electronics ground
|
|
Analog outputs (AO)
|
||
|
12
|
AO0+
|
Non-isolated output
Freely programmable Value range: 0 ... 10 V; 0/4 ... 20 mA |
|
13
|
GND
|
Reference potential of the AO0/internal electronics ground
|
|
26
|
AO1+
|
Non-isolated output
Freely programmable Value range: 0 ... 10 V; 0/4 ... 20 mA |
|
27
|
GND
|
Reference potential of the AO1/internal electronics ground
|
|
Motor temperature sensor interface
|
||
|
14
|
T1 MOTOR
|
Positive input for motor temperature sensor
Type: PTC, KTY sensor, bimetal |
|
15
|
T2 MOTOR
|
Negative input for motor temperature sensor
|
|
Power supply
|
||
|
9
|
+24 V OUT
|
Power supply output
24 VDC, max. 100 mA |
|
28
|
GND
|
Reference potential of the power supply/internal electronics ground
|
|
1
|
+10 V OUT
|
Power supply output
10 V DC ±0.5 V, max. 10 mA |
|
2
|
GND
|
Reference potential of the power supply/internal electronics ground
|
|
31
|
+24 V IN
|
Power supply input
20.4 ... 28.8 V DC, max. 1500 mA |
|
32
|
GND IN
|
Reference potential of the power supply input
|
|
35
|
+10 V OUT
|
Power supply output
10 V DC ±0.5 V, max. 10 mA |
|
36
|
GND
|
Reference potential of the power supply/internal electronics ground
|
We Could Supply Full Range Of SIEMENS.
If you find the SIEMENS part that you are looking for, pls Skype / Email us for a quote.
If you have any questions, also pls Skype / Email us.
